CE
Disposal instructions according to 2012/19/EU
Do not cover with heat insulting materials
Only suitable for indoor installations
Parallel connection
Protection class I
RoHS
Product number:
48120
SILMA LED-EBS AC RUND WEISS 20W IP40
Product information "SILMA LED-EBS AC RUND WEISS 20W IP40"
- for indoor use, IP40
- housing: diecast aluminum (plastic protection cover, diffuse)
- housing colour: white
- not swivelling
- beam angle: 102°
- power: 20 W
- light colour: 3000 K ( 100K) warm white
- luminous flux: 1960 lm
- CRI: >80
- lifespan L70: >= 50.000 h
- input: 220-240 V AC
- protection class I
- installation depth: 60 mm
- ceiling cut-out: 165 mm
- outer diameter: 195 mm
- not dimmable
- suitable for through wiring
Technical Data
| BAR code: | 4012094481203 |
|---|---|
| Height: | 52 mm |
| Unit Code: | piece |
| Customer discount group code: | R2 |
| Installation diameter: | 165 mm |
| Outer diameter: | 195 mm |
| Lumen per fixture (lm): | 1960 lm |
| Lumen per LED (lm): | 35,00 lm |
| Installation depth: | 60 mm |
| Temperature range: | -20 - 50 |
| Lumen per watt: | 98 |
| IP protection rating: | 40 |
| Power: | 20 W |
| CRI: | 80 |
| Catalog color code: | weiss |
| Led color code: | ca. 3000K warmweiß |
| Leuchte: | including LED |
| Beam angle: | 102 Grad ° |
| Voltage: | 220-240 V |
| Sockel code: | ohne |
| Anzahl led: | 56 |
| Gehaeuse code: | Aluminium |
| Auslaufartikel: | Yes |
| L70: | 50000 |
| Ecodesign: | light source |
