CE
Parallel connection
Protection class III
RoHS
UV-resistant
Product number:
S86262-V2
S?-?? Flex.LEDStrip,24V,Blau
Product information "S?-?? Flex.LEDStrip,24V,Blau"
- MOQ 100m
- Flexible LED Stripe sealed in UV-, chlorine-,
- salt water-, solventresistant blue PVC
- for indoor- and outdoor use, IP68
- Cuttable every 83.33 mm / 6 LEDs
- Amount of LEDs per meter: 72
- LED pitch: 13.89 mm
- Beam angle: 120°
- Wavelength: 468 - 474 nm
- Luminous flux per meter: 20 lm
- Voltage: 24V DC
- Power per Meter: 12 W
- Lifetime L70: >= 36.000 h
- Energy efficiency class: E
- WxH in mm: 11.5 x 21
- Temperature range: -10 to +45°C
- Processing temperature: +10 to +45°C
- Maximum length per connection: 10 meter
- Bending diameter: 120 mm
Technical Data
| BAR code: | 4012094232621 |
|---|---|
| Width: | 11 mm |
| Height: | 21 mm |
| Unit Code: | meter |
| Lumen per LED (lm): | 0,28 lm |
| Temperature range: | -10 - 45 |
| LEDs per meter: | 72 |
| Cutting length in mm: | 83,33 mm |
| Power W/m: | 12 |
| Lumen per meter: | 20 |
| Lumen per watt: | 1,67 |
| IP protection rating: | 68 |
| Catalog color code: | blau |
| Led color code: | Blau |
| Leuchte: | including LED |
| Beam angle: | 120 Grad ° |
| Voltage: | 24 V |
| Gehaeuse code: | Kunststoff |
| Re skus: | 68314,68317,68318 |
| Auslaufartikel: | Yes |
| L70: | 36000 |
| LebensdauerL70B50: | 36000 |
| Ecodesign: | not relevant |
