CE
Disposal instructions according to 2012/19/EU
Only suitable for indoor installations
Parallel connection
Protection class III
RoHS
Very light - profile necessary
Product number:
81745
LD Flexible LED Leiste,Innen RGBW-3000
Product information "LD Flexible LED Leiste,Innen RGBW-3000"
- flexible LED Strip with self adhesive backside,
- for indoor use.
- Each individual LED separately programmable
- and individually controllable
- can be seperated every 8.33 mm or each LED
- number of LEDs: 600
- IC type: SK6812 IC
- LED pitch: 8.33 mm
- beam angle: 120°
- CRI: >80
- luminous flux per meter: 1220 lm
- voltage: 5 V DC
- power per meter: 28.8 W
- lifetime L70B50: >= 32.000 h
- energy efficiency class: D
- LxWxH in mm: 5,000 x 12 x 2.1
- Caution: Do not operate strip without aluminium profile
- and adequate ventilation.
- Maximum length per connection: 5 meter. New connectors for greater length.
- Delivery contents: 5 meter reel
Technical Data
| BAR code: | 4012094817453 |
|---|---|
| Width: | 12 mm |
| Height: | 2 mm |
| Length: | 5000 mm |
| Unit Code: | piece |
| Customer discount group code: | R2 |
| Lumen per fixture (lm): | 6100 lm |
| Lumen per LED (lm): | 10,17 lm |
| Current: | 28800 mA |
| Temperature range: | -20 - 65 |
| LEDs per meter: | 120 |
| Cutting length in mm: | 8,33 mm |
| Power W/m: | 28,8 |
| Lumen per meter: | 1220 |
| Lumen per watt: | 42,36 |
| IP protection rating: | 20 |
| Power: | 144 W |
| Energy efficiency class: | EEK-Label_D |
| CRI: | 80 |
| Led color code: | RGBW 3000K |
| Leuchte: | including LED |
| Beam angle: | 120 Grad ° |
| Voltage: | 5 V |
| Anzahl led: | 600 |
| L70: | 60000 |
| LebensdauerL70B50: | 32000 |
| Ecodesign: | light source |
