Product number:
71435
LD Flex.LEDStrip,Innen,2700K CRI95 IP67
Product information "LD Flex.LEDStrip,Innen,2700K CRI95 IP67"
- flexible LED-strip with self adhesive backside,
- for indoor and outdoor use, IP67
- can be seperated every 33.33 mm or 7 LEDs
- number of LEDs: 1050
- LED pitch: 4.76 mm
- beam angle: 120°
- CRI: >95
- luminous flux per meter: 1065 lm
- input: 24V DC
- power per meter: 6 W
- lifetime L70B50: >= 33,000 h
- energy efficiency class: E
- LxWxH in mm: 5,000 x 11.5 x 4.5
- Maximum length per connection: 5 meter. New connectors for greater length.
- Delivery contents: 5 meter reel with 300 mm connecting cable,
- 10 x mounting bracket
Technical Data
| BAR code: | 4012094714356 |
|---|---|
| Width: | 11 mm |
| Height: | 4 mm |
| Length: | 5000 mm |
| Unit Code: | piece |
| Customer discount group code: | R2 |
| Lumen per fixture (lm): | 5325 lm |
| Lumen per LED (lm): | 5,07 lm |
| Current: | 2083 mA |
| Temperature range: | -20 - 45 |
| LEDs per meter: | 210 |
| Cutting length in mm: | 33,33 mm |
| Power W/m: | 10 |
| Lumen per meter: | 1065 |
| Lumen per watt: | 106,5 |
| IP protection rating: | 67 |
| Power: | 50 W |
| Energy efficiency class: | EEK-Label_E |
| CRI: | 95 |
| Led color code: | ca. 2700K ultra warmweiß |
| Leuchte: | including LED |
| Beam angle: | 120 Grad ° |
| Voltage: | 24 V |
| Anzahl led: | 1050 |
| Gehaeuse code: | Kunststoff |
| L70: | 50000 |
| LebensdauerL70B50: | 33000 |
| Ecodesign: | light source |
| Psb: | 0,00 |
| Service life L90B10: | 25000 |
