CE
Disposal instructions according to 2012/19/EU
Low voltage correction
Only suitable for indoor installations
Parallel connection
Protection class III
RoHS
Very light - profile necessary
Product number:
82875
LD Flex.LEDStrip,24V,Innen,3000K CRI90
Product information "LD Flex.LEDStrip,24V,Innen,3000K CRI90"
- flexible LED Strip with self adhesive backside,
- for indoor use.
- can be seperated every 25 mm or 7 LEDs
- number of LEDs: 1400
- LED pitch: 3.57 mm
- beam angle: 120°
- CRI: >90
- lumen per meter: 1860 lm
- voltage: 24V DC
- power per meter: 19.2 W
- lifetime L70B50: >= 33,000h
- LxWxH in mm: 5.000 x 10 x 2
- Caution: Do not operate strip without aluminium profile
- and adequate ventilation
- Maximum length per connection: 5 meter. New connectors for greater length.
- Delivery contents: 5 meter roll
Technical Data
| BAR code: | 4012094828756 |
|---|---|
| Width: | 10 mm |
| Height: | 2 mm |
| Length: | 5000 mm |
| Unit Code: | piece |
| Customer discount group code: | R2 |
| Lumen per fixture (lm): | 9300 lm |
| Lumen per LED (lm): | 6,64 lm |
| Current: | 4000 mA |
| Temperature range: | -20 - 45 |
| LEDs per meter: | 280 |
| Cutting length in mm: | 25 mm |
| Power W/m: | 19,2 |
| Lumen per meter: | 1860 |
| Lumen per watt: | 78,95 |
| IP protection rating: | 20 |
| Power: | 96 W |
| Energy efficiency class: | EEK-Label_F |
| CRI: | 90 |
| Catalog color code: | weiss |
| Led color code: | ca. 3000K warmweiß |
| Leuchte: | including LED |
| Beam angle: | 120 Grad ° |
| Voltage: | 24 V |
| Anzahl led: | 1400 |
| Auslaufartikel: | Yes |
| L70: | 36000 |
| LebensdauerL70B50: | 33000 |
| Ecodesign: | light source |
