CE
Disposal instructions according to 2012/19/EU
Light source not interchangeable
Parallel connection
Protection class III
RoHS
UV-resistant
Product number:
S71904
LD EX-Outdoor LED-Flex. 6500K
Product information "LD EX-Outdoor LED-Flex. 6500K"
- flexible LED strip EX protected and sealed in UV, solvent and salt water
- resistant white silicone
- for indoor and outdoor use, IP67
- cuttable every 83.33 mm or 7 LEDs
- amount of LEDs per meter: 84
- LED pitch: 11.90 mm
- beam angle: 120°
- CRI: >80
- luminous flux per meter: 1000 lm
- power per meter: 12 W
- lifespan L70: >= 50.000 h
- WxH in mm: 20 x 10
- ambient working temperature: -30 bis +40°C
- ambient installation temperature: +10 bis +40°C
- maximum length per connection: 20 meter
- bending radius vertical: 75 mm
Technical Data
| BAR code: | 4012094719047 |
|---|---|
| Width: | 20 mm |
| Height: | 10 mm |
| Unit Code: | meter |
| Customer discount group code: | R2 |
| Lumen per LED (lm): | 0,00 lm |
| Temperature range: | -30 - 40 |
| LEDs per meter: | 84 |
| Cutting length in mm: | 8,33 mm |
| Power W/m: | 12 |
| Lumen per meter: | 1000 |
| Lumen per watt: | 83,33 |
| IP protection rating: | 67 |
| CRI: | 80 |
| Catalog color code: | weiss |
| Led color code: | ca. 6500K kaltweiß |
| Leuchte: | including LED |
| Beam angle: | 120 Grad ° |
| Voltage: | 24 V |
| Gehaeuse code: | Kunststoff |
| Auslaufartikel: | Yes |
| L70: | 50000 |
| Ecodesign: | containing product |
