Product number:
700159
LD Calina adj. 17W RGBW 2700K 40° white IP65 D125 DC24V 96.052.4053.9
Product information "LD Calina adj. 17W RGBW 2700K 40° white IP65 D125 DC24V 96.052.4053.9"
- RGBW LED recessed downlight
- for indoor and outdoor use. IP65
- housing: diecast aluminum
- housing color: white
- can be swivelled 2 x 15°
- beam angle: 40°
- power: 17 W (white 6.5 W)
- light color: 2700K + RGB
- luminous flux: 655 lm
- luminous flux 2700K: 390 lm
- CRI: >90
- lifetime: L70B50: >= 50.000 h
- input voltage: 24 V DC
- installation depth: 100 mm
- ceiling cut-out: 108 mm
- outer diameter: 125 mm
- energie efficiency class: G
- not including LED converter
Technical Data
| BAR code: | 4251835701594 |
|---|---|
| Height: | 90 mm |
| Unit Code: | piece |
| Installation diameter: | 108 mm |
| Outer diameter: | 125 mm |
| Lumen per fixture (lm): | 655 lm |
| Lumen per LED (lm): | 0,00 lm |
| Installation depth: | 100 mm |
| Temperature range: | -20 - 45 |
| Lumen per watt: | 38,53 |
| IP protection rating: | 65 |
| Power: | 17 W |
| Energy efficiency class: | EEK-Label_G |
| CRI: | 90 |
| Catalog color code: | weiss |
| Led color code: | ca. 2700K ultra warmweiß |
| Leuchte: | including LED |
| Beam angle: | 40 Grad ° |
| Voltage: | 24 V |
| Anzahl led: | 1 |
| Gehaeuse code: | Aluminium |
| LebensdauerL70B50: | 50000 |
| Ecodesign: | light source |
| Psb: | 0,00 |
