CE
Disposal instructions according to 2012/19/EU
Parallel connection
Protection class III
RoHS
Product number:
88566
Flex.LED im Schlauch,IP68,RGB
Product information "Flex.LED im Schlauch,IP68,RGB"
- Flexible LED Strips in Silicone Tubing
- for Indoor and Outdoor Use
- For Indoor and Outdoor Use
- RGB 12 Volt: Separable Every 100 mm or 3 LEDs
- LED Distance: RGB: 33.33 mm (150 LED)
- Easy Installation with Solder-less Plug Connections.
- Maximum Length per Connection: 10 meter
- New Connectors for Greater Lengths.
- Delivery Contents: 5 Meter Roll, 5 Power Supply Connector, 1 Direct
- Connector, 1 Connection Tubing, 30 Mounting
- Brackets, 2 End Caps, 2 Power Supply Connector Caps
- Sorted and Stored by Binning Code
Technical Data
| BAR code: | 4012094885667 |
|---|---|
| Width: | 13 mm |
| Height: | 4 mm |
| Length: | 5000 mm |
| Unit Code: | piece |
| Customer discount group code: | ST |
| Lumen per fixture (lm): | 1100 lm |
| Lumen per LED (lm): | 7,33 lm |
| Current: | 3000 mA |
| Temperature range: | -20 - 45 |
| LEDs per meter: | 30 |
| Cutting length in mm: | 100 mm |
| Power W/m: | 7,2 |
| Lumen per meter: | 220 |
| Lumen per watt: | 30,56 |
| IP protection rating: | 68 |
| Power: | 36 W |
| Catalog color code: | weiss |
| Led color code: | RGB |
| Leuchte: | including LED |
| Beam angle: | 120 Grad ° |
| Voltage: | 12 V |
| Anzahl led: | 150 |
| Gehaeuse code: | Kunststoff |
| L70: | 36000 |
| LebensdauerL70B50: | 67000 |
| Ecodesign: | light source |
| Service life L90B10: | 35000 |
