CE
Disposal instructions according to 2012/19/EU
Parallel connection
Protection class III
RoHS
Product number:
86564
Flex.LED Strip,24V,IP68,6500K
Product information "Flex.LED Strip,24V,IP68,6500K"
- Flexible LED Strips in a Silicone Tubing
- for Indoor and Outdoor Use
- Separable Every 5 cm or 3 LEDs
- (24 Volt: Separable Every 10 cm or 6 LEDs)
- LED Distance: Single Color 16 mm (300 LED)
- Easy Installation with Solder-less Plug Connections.
- Maximum Length per Connection: 10 Meter. New Connectors for Greater Lengths.
- lifetime L70B50: >= 72.000 h
- Delivery Contents: 5 Meter Roll, 5 Power Supply Connector, 1 Direct Connector,
- 1 Connection Tube, 30 Mounting Brackets, 2 End Caps, 2
- Power Supply Connecting Caps
- Sorted and Stored by Binning Code
- energy efficiency class: F
Technical Data
| BAR code: | 4012094865645 |
|---|---|
| Width: | 11 mm |
| Height: | 4 mm |
| Length: | 5000 mm |
| Unit Code: | piece |
| Customer discount group code: | ST |
| Lumen per fixture (lm): | 2300 lm |
| Lumen per LED (lm): | 7,67 lm |
| Current: | 1000 mA |
| Temperature range: | -20 - 45 |
| LEDs per meter: | 60 |
| Cutting length in mm: | 100 mm |
| Power W/m: | 4,8 |
| Lumen per meter: | 460 |
| Lumen per watt: | 95,83 |
| IP protection rating: | 68 |
| Power: | 24 W |
| Energy efficiency class: | EEK-Label_F |
| CRI: | 80 |
| Catalog color code: | weiss |
| Led color code: | ca. 6500K kaltweiß |
| Leuchte: | including LED |
| Beam angle: | 120 Grad ° |
| Voltage: | 24 V |
| Anzahl led: | 300 |
| Gehaeuse code: | Kunststoff |
| Re skus: | 68306,80474,85271 |
| L70: | 36000 |
| LebensdauerL70B50: | 72000 |
| Ecodesign: | light source |
| Psb: | 0,00 |
| Service life L90B10: | 35000 |
