Product number:
68255
ALU-Profil Stufe indirekt
Product information "ALU-Profil Stufe indirekt"
- Alu Profile Stair indirect
- for strips up to 12 and 6 mm in width
- Material: Aluminium anodised
- For flexible LED strips and rigid strips up to 12,2 mm in
- width (indirect lighting at the front) upper lighting max. 6 mm width
- For indoor use
- Length: 2 metres + 3 metres
- Matt cover for lighting at the top or anti-slip rubber (grey)
- Side LED strip brings about a homogeneous upper lighting
- Covering material: polycarbonate, UV-resistant and rupture-free
- Cover can be aesily fitted and simantled by clicking in at the front
- For accident prevention reasons, we would suggest bolting
- the stair profiles
- Delivery without cover, anti-slip rubber and end caps -
- please order them separately
- Note: Not for VARDAflex fin-feeder and direct connectors
Technical Data
| BAR code: | 4012094682556 |
|---|---|
| Width: | 82 mm |
| Height: | 46 mm |
| Length: | 2000 mm |
| Unit Code: | piece |
| Customer discount group code: | R2 |
| Lumen per LED (lm): | 0,00 lm |
| IP protection rating: | 20 |
| Catalog color code: | aluminium |
| Leuchte: | without |
| Gehaeuse code: | Aluminium |
| Re skus: | 68258,68259,68298,68299 |
| Auslaufartikel: | Yes |
| Ecodesign: | not assigned |
